9 Color for choose. Red ,Blue, Yellow, Green, White, Black,Brown, purple, orange 1. Excellent electrical and mechanical protection from combined pressure-sensitive, rubber-resin adhesive and PVC backing 2
Product Specification:
These Machine accessories May you like
1. Excellent electrical and mechanical protection from combined pressure-sensitive, rubber-resin adhesive and PVC backing
2. Pressure sensitive rubber adhesive bonds easily and securely
3.Suitable for use in phase identification, color coding of motor leads and piping systems and for marking safety areas
4.Tensile strength rating of 17 lbs. per inch meets professional electrical standards
|
Attribute Name |
Value |
|
Adhesion to Steel |
2,2 N/cm, 20 oz/in (2,2 N/cm) |
|
Adhesion to Steel oz/in (N/100 mm) |
30 (33), 40 (44) |
|
Adhesive Material |
Rubber Resin |
|
Agency Approvals |
CSA Certified, UL Listed |
|
Applications |
Electrical Maintenance |
|
Backing Material |
Polyvinyl Chloride, Vinyl |
|
Backing Thickness (metric) |
0.18 mm |
|
Breaking Strength |
17 lb/in |
|
Color |
Blue, Brown, Gray, Green, Multi-Color, Orange, Pink, Red, Violet, White, Yellow |
|
Dielectric Strength (V/mil) |
1250, 1250 V/mil |
|
Material |
PVC |
|
Operating Temperature Range (Celsius) |
0 °C to 105 °C |
|
Product Type |
Vinyl Electrical Tapes |
|
RoHS 2011/65/EU Compliant |
Yes |
