3m vhb 4229p double sided tape Acrylic Foam Tape for for Automotive Trim Edge

Log Roll size : 600mm x 33meter

Product Specification:
  • Name : 3m 4229p vhb tape
  • Size : customize Shape
  • Color : Grey
  • Thickness : 0.8mm
INQUIRY NOW
Product Details

3m 4229p vhb tape, double sided tape 4229p

Product name

3M tape 4229P

Color

Grey

Backing

proply acid

Adhesive

acrylic solvent based

Liner Type

Red Polyethylene Film

Tack

>=6#

Tensile strength

>=20N/25MM

Temperature Resistance - Initial

200 Degree Fahrenheit

Temperature Resistance - Long Term

130 Degree Fahrenheit

180 peeling

>=14N/25MM

Enogation %

>=24/25mm

Density

688kg/m3 (43 lb/ft3)

Breakaway Peel

8.6 kg (19 lbs.)

Continuing Peel

4.1 kg (9 lbs.)



3M Double Sided Acrylic Foam Tape 4229P is a 0.76mm thick, gray, heat resistant tape commonly used for the attachment of automotive exterior trim parts such as body side moldings. It has a red polyethylene release liner imprinted with the 3M logo.

Typical applications would include body side moldings; stainless steel, ABS and PVC rocker panels; wheel lip moldings, door edge moldings, nameplates ornamentation, luggage rack slats, wind and rain deflectors, and dashboard

3m 4229p vhb tape, double-sided tape 4229p

3M Pressure Sensitive Acrylic Foam Tape 4229P is characterized by high performance peel and shear adhesion, high internal strength, good conformability and excellent plasticizer resistance. The acrylic foam core has unique viscoelastic properties that allow it to elongate and relax when put under load, thereby minimizing stress on the adhesive bond line. These properties allow the tape to bond moreeffectively to a wide variety of automotive surfaces.

3m 4229p vhb tapedouble sided tape 4229p3m 4229p vhb tape

Welcome to inquire 3m 4229p vhb tape, double sided tape 4229p
